class: center, middle, title ## Richard Marmorstein and the ## Legend of #Qwertsichord Slides at http://twitchard.github.io/brooklynjs/index.html
Your destiny awaits
??? --- class: bigpicture ![me](qw1.jpg) --- class: bigpicture ![me](qw2.jpg) --- class: bigpicture ![me](qw3.jpg) ??? I have an inferiority complex about it. --- class: bigpicture ![me](qw4.jpg) ??? Empire Node, beginning of November Justin J. Moses: inspiration "The Sound of Music" node-keyboard --- # What you will learn ### It is easy to implement a musical application in Node.js --- # What you will learn ### It is easy to implement a musical application in Node.js ### It is delightful to implement a musical application in Node.js --- # What you will learn ### It is easy to implement a musical application in Node.js ### It is delightful to implement a musical application in Node.js ### It is **your personal destiny** to implement your very own musical instrument in Node.js. ??? After this presentation, you will experience true clarity of purpose. --- ## What is Qwertsichord * Turn your qwerty keyboard into a fun musical instrument. * No GUI. * GNU/Linux only. --- ## What is Qwertsichord * Turn your qwerty keyboard into a fun musical instrument. * No GUI. * GNU/Linux only. **Just imagine** - Raspberry pi - usb keyboard - usb speakers - amazing live performance - legions of adoring fans --- class: center # Making a musical instrument in two lessons ## 1. When you press keys... --- class: center # Making a musical instrument in two lessons ## 1. When you press keys... ## 2. it makes sound --- ## 1. When you press keys #### `.on('keyup')` and `.on('keydown')`? --- ## 1. When you press keys
.on('keyup') and .on('keydown')?
Alas, no such thing in Node.js
--- ## 1. When you press keys
.on('keyup') and .on('keydown')?
Alas, no such thing in Node.js
`process.stdin.on('keypress')`? --- ## 1. When you press keys
.on('keyup') and .on('keydown')?
Alas, no such thing in Node.js
process.stdin.on('keypress')
?
Inadequate.
--- ## 1. When you press keys
.on('keyup') and .on('keydown')?
Alas, no such thing in Node.js
process.stdin.on('keypress')
?
Inadequate.
`npm install node-sdl`? --- ## 1. When you press keys
.on('keyup') and .on('keydown')?
Alas, no such thing in Node.js
process.stdin.on('keypress')
?
Inadequate.
npm install node-sdl
?
Too complicated/"finicky"
--- # npm install xev-emitter - Processes output of 'xev' command. - Written by trusted author. - True to the UNIX philosophy. --- ``` // example.js const xevEmitter = require('xev-emitter')(process.stdin) xevEmitter.on('KeyPress', (key) => { console.log(key, 'was pressed') }) xevEmitter.on('KeyRelease', (key) => { console.log(key, 'was released') }) ``` **Run it:** ``` $ xev | node example.js a was pressed b was pressed b was released ``` --- # Making a musical instrument in two lessons ## 1. When you press keys ## 2. It makes sound. --- ## 2. It makes sound. --- ## MIDI ### *Musical Instrument Digital Interface* Decouples 'choosing what notes to play' (MIDI 'controller') from 'producing the sound of the note' (MIDI 'sound module') ??? Published in August 1983 --- ## Yay for MIDI Qwertsichord can outsource the hard part, 'producing the sound of the note' to some other program. Many choices on Linux - 'zynaddsubfx' - 'amsynth' - 'FLUIDsynth' --- ## MIDI ![Midi table](miditable.png) --- **npm install midi** [github.com/justinlatimer/node-midi](https://github.com/justinlatimer/node-midi#) ``` var midi = require('midi') var output = new midi.output() console.log(output.getPortCount()) // "2" console.log(output.getPortName(0)) // "Midi Through 14:0" console.log(output.getPortName(1)) // "FLUID Synth (2188) 128:0" output.openPort(1) // Connect to FLUID Synth output.sendMessage([144, 60, 90]) // Play middle C setTimeout(function () { output.sendMessage([128, 60, 40]) // Stop playing middle C }, 1000) ``` ??? Still too hard? Who here wants to send magic numbers everywhere --- ## npm install easymidi ``` var easymidi = require('easymidi'); var output = new easymidi.Output('FLUID Synth (2188) 128:0'); output.send('noteon', { note: 64, // E above middle C velocity: 127, channel: 3 }); ``` ??? const outputName = easymidi.getOutputs().filter(RegExp.prototype.test.bind(/FLUID/))[0] --- ## Qwertsichord - Not just a piano. Pianos are boring. - You count in binary to go up the scale. - Your right hand is a pipe that plays a single note at a time. - Your left hand is 'drones' that layers notes on and off. - Not just any QWERTY keyboard will do, unfortunately --- ### Excerpts from the source code ``` // Initializing the instrument const MELODY_KEYS = [ 'j', 'k', 'l', ';' ] const MELODY_SHARP_KEY = 'h' const melodyPipe = new MelodyPipe( 0, // MIDI Channel 20, // MIDI Program output, // From easymidi MELODY_KEYS, MELODY_SHARP_KEY ) melodyPipe.connect(xevEmitter) ``` --- ``` // playing a note class MelodyPipe { ... play (note) { // Stop playing the previous note if (this.note) { this.output.send('noteoff', this.note) } // Start playing the new note if (note) { const send = { note, velocity: VELOCITY, channel: this.channel } this.output.send('noteon', send) this.note = send } } ... } ``` --- ``` // Keep track of what keys are pressed class MelodyPipe { ... connect (xevEmitter) { xevEmitter.on('KeyPress', (key) => { this.pressedKeys.add(key) this._refresh() }) xevEmitter.on('KeyRelease', (key) => { this.pressedKeys.delete(key) this._refresh() }) } ... } ``` --- ``` // Determining what note to play: class MelodyPipe { ... _refresh() { ... let num = 0 let mult = 1 this.melodyKeys.map((x) => { if (this.pressedKeys.has(x)) { num += mult } mult *= 2 }) const sharp = this.pressedKeys.has(this.sharpKey) ? 1 : 0 if (num === 0) { this.play(null) } else { this.play(BASE_NOTE + ionianScale(num - 1) + sharp) } ... } ... } ``` --- ## Live Demo Fork me on github! https://github.com/twitchard Follow me on Twitter! https://twitter.com/twitchard
